Description

MT90 motor with 66 rpm gearbox

MT90 brush motor with gearbox operating at 12V DC supply voltage. The speed achieved at 12V is 66 rpm. The motor is used in a variety of robots, manipulators, toys and your own DIY projects.

Low-noise

Long life DC motor features high torque and low noise level. Solidly built and ready for installation in many projects where high power is needed.

Technical data

• Supply voltage: 12V
• Idle current: less than 0.05A
• Peak current: 1.2A
• Torque: 42kg*cm (4.2Nm)
• RPM at idle at 12V: 66
• Dimensions: 37x45mm
• Shaft diameter: 6mm
• Shaft length: 15mm
• Height of gear x: 23.7mm
