Description

Li-ion 1S 3.7V 3A cell charging module

Electronic circuit that protects 1S battery from discharge and at the same time charger for these batteries. Allows you to build a safe battery pack that does not need to be charged with special chargers for li-ion batteries.

The 2-in-1 module will keep the cells in the best possible conditions without allowing them to overcharge as well as over-discharge. One module here replaces the charger and security module.

More information about BMS modules, their application and how they work HERE.

Product features

• Short circuit protection.
• Protection against overcharging.
• Over-discharge protection.
• Overcurrent protection.
• Can be used for a variety of lithium cells 3.7V.
• Compact size and light weight
• Ensures safe use of the battery

Technical data

• Maximum charging voltage: 4.25±0.05V
• Minimum discharge voltage: 2.54±0.1V
• Max. operating charging current: 2A
• Max. discharge operating current: 2A
• Dimensions: 67*16*1.0mm

Included

• Li-ion cell charging and protection module – 1S – 3.7V – 3A – for 18650 cells – 1pc.
