Description

Li-ion 3S 12V 10A charging BMS module

BMS 3S 12V 10A – Electronic circuit that protects batteries from discharging and at the same time a charger for these batteries.

Allows you to build a safe battery pack that does not need to be charged with special chargers for li-ion batteries.

The 2-in-1 module will keep the cells in the best possible conditions without allowing them to overcharge as well as over-discharge. One module here replaces the charger and security module.

Product Features BMS 3S 12V:

• Short circuit protection.
• Protection against overcharging.
• Over-discharge protection.
• Overcurrent protection.
• Can be used for a variety of lithium cells 3.7V.
• Compact size and lightweight.
• Ensuring the safety of the battery.
• Size: 50x21x1mm
• Maximum discharge current: 9A
• Voltage detection overload: 4.25-4.35V ± 0.05 V
• Over-discharge voltage detection: 2.3-3.0V ± 05V
• Maximum operating current: 9A
• Maximum instantaneous current: 10A – 15A
• Operating temperature: -40 ~ 50 degrees
• Storage temperature: -40 ~ 80 degrees
• Resting current: pon. 50uA
• Internal resistance: pon. 100mΩ
• Lifetime: pow. 30,000 hours
