Description

Li-ion 3S STANDARD charging module – 12.6V – 40A

BMS 3S electronic system in STANDARD version working as a battery protection against over-discharge and over-charging.

• Allows you to build a safe battery pack that does not need to be charged with special chargers for li-ion batteries.
• The 2-in-1 module was created to keep the cells in the best possible condition by not allowing them to overcharge as well as over-discharge.
• One module here replaces the charger and security module.
• In the STANDARD 2.3 version, the anti-interference function has been improved, the heat dissipation has been reduced by 30% and there is no current limitation so even at high currents it will not disconnect the power supply.
• More information about BMS modules, their application and how they work HERE.
• NOTE!!! this module comes in 3 versions: Standard, Balance, Balance + short circut.

Features of BMS 3S

• Protection against overcharging.
• Excessive Discharge Protection.
• Can be used for a variety of lithium cells 3.7V.
• Compact size and lightweight.
• Ensure the safety of the battery.

Technical data BMS 3S

• Charging voltage: 12.6V – 13.6V
• Maximum discharge current: 40A
• Continuous charging current (upper limit): 20A
• Dimensions: 60x41x3.4mm
