Description

5A DC-DC inverter XL4005E1 for FPV

High current (5A), freely adjustable converter from 4V to 38V – to adjustable voltage from 1.25V to 36V.

This device allows safe, stable power supply of electronics, FPV (cameras, etc.) on stabilized constant voltage.

Parameters

• Input voltage : 4-38V
• Adjustable output voltage : 1.25-36V
• Maximum output current: 5A
• Output power: 75W
• Efficiency: Max 92%
• Frequency: 180kHz – 48KHz
• Potentiometer: W503 – 50K Ohms
• Operating temperature: -40 ℃ to +85 ℃ (power in 10W)
• Short circuit protection: current limitation up to 8A, Auto-CV
• Weight: 17g
• Size: 54x23x18 mm

Comments

• This device regulates voltage by lowering (not raising) the voltage. The supply voltage must be greater than the consumer voltage.
• Incorrect connection of power supply polarity causes damage to inverter
• This device is intended for experienced do-it-yourselfers, basic knowledge of elelktronics and soldering skills are required. The company is not responsible for damages resulting from lack of soldering skills or poorly made electrical installations.
• Check the output voltage and adjust with the proper potentiometer and only then connect the receiving device
