Description

12v 1.5A stabilized power supply module on LM7812

Power supply module equipped with an LM78S12 stabilizer with built-in filter capacitors and diodes for any + and – DC power supply and AC power supply connection.

Note that with a heavy load, the stabilizer can be damaged and internally make a short circuit between the input and output!

Technical data

• Module equipped with LM7812 stabilizer
• Input voltage: 14 – 35V DC
• Input voltage: 12 – 18V AC
• Output voltage: 12V DC
• Max. output current: 1.5A
• 2 terminalblock ARK connectors (for supply voltage and output voltage)
• Built-in filter capacitors
• Heat sink – ensures proper heat dissipation from the system
• 4 M3 mounting holes
• Dimensions: 26 x 49mm
• Outputs:
• Terminal block (ARK2) AC connector – module power supply
• Terminal block connector (ARK2) + and – – output voltage
