Description

XT60-H plugs with shield – black – Male and female connector – high current connector

The new XT60+ plugs from Amass are high-current excellent quality connectors that allow very good polarization isolation for soldered connections. Slowly becoming the most popular connector for hobbyists, displacing standard XT60 connectors. The basic design of the original XT60 connector has been retained and is compatible with the newer version.

• Soldering is required for proper connection, and thanks to the snaps on the ends, there is no need for heat shrink tubing. Serrated edges make it easier to handle plugs provide a better grip so the connector is easier to undo.
• Additional covers on the side of the wires provide additional insulation for them, as well as stiffening, so that the soldered connector will have a longer service life.

Product features

• The construction of the connectors allows the use of wires with a cross-section: from 1 to 5mm2.
• Contacts with very low connector resistance, very large connection area.
• Compact connector design.
• Gold-plated high-current contacts (built on gold 3.5mm2).
• It is characterized by small size, low weight and efficient current performance.
• XT60 is minimally larger than the XT60U connector.
• The connectors are mostly used in the connections between the speed controller and the battery.
• The special design of the connector on 3.5mm gold allows it to work on high current and also protects against reverse plugging.

Technical data

• Material: gold-plated copper
• Case: Nylon/PA
• Maximum continuous current / Peak current: 60A/100A
• Temperature resistance: -20°C~120°C
• Recommended wire: 12AWG
• Color: Black

Included

• XT60-H plugs with shield – Male connector – 1 pc
• XT60-H plugs with shield – Female connector – 1 pc
• Shield – 2 pcs

Additional Information

Want to know more about the plugs used in modeling – click here -> A guide to the plugs and connectors used in RC modeling
